SERVICE OVERVIEW

What Is Detailed Engineering And Design?

Detailed engineering and design is the engineering phase that turns an approved concept or basic engineering package into a full set of drawings, calculations, and documents needed to build and install a physical facility or plant.

It covers every engineering discipline: process, piping, mechanical, civil, structural, electrical, and instrumentation. DED comes after the front-end engineering and design (FEED) phase.

The output of detailed engineering is a complete construction package. This includes P&IDs, general arrangement drawings, equipment datasheets, material take-offs, and instrument loop diagrams. Without detailed engineering, a project cannot move to construction.

Monarch Innovation delivers complete multi-discipline detailed engineering for greenfield plants, brownfield expansions, and plant upgrades. Our engineering packages are designed to be correct, coordinated, and ready for construction on the first issue.

What Does a Detailed Engineering Package Include?

Process flow diagrams (PFDs) and piping and instrumentation diagrams (P&IDs).
Equipment specifications and datasheets.
3D plant model and clash-detection reports.
Piping isometrics and pipe stress analysis.
Civil and structural drawings and calculations.
Electrical single-line diagrams and cable schedules.
Instrument index, loop diagrams, and hook-up drawings.
Material take-offs (MTOs) for bulk procurement.
Vendor document review and management.

Engineering team reviewing detailed design drawings and a 3D CAD model around a table of construction blueprints

Why Do Projects Need Detailed Engineering Services?

Detailed engineering prevents costly mistakes during construction. When engineering drawings are unclear, incomplete, or uncoordinated, projects face delays, rework, and cost overruns. A quality detailed engineering package ensures your construction team has everything they need before the first piece of steel is ordered.

DED is the phase between FEED and construction.

Monarch Innovation uses 3D plant modeling to eliminate clashes before construction begins.

It covers all engineering disciplines in one coordinated package.

Poor DED is the leading cause of construction rework and schedule overruns on capital projects.

SERVICE OFFERINGS

What Detailed Engineering Services Does Monarch Innovation Provide?

We cover every engineering discipline under one coordinated program. Here is what is included in a Monarch Innovation DED engagement.

Full process definition from PFD to IFC P&ID

Process Engineering and P&ID Design

We design and finalize all process flow diagrams, P&IDs, utility balance documents, and cause-and-effect matrices. These documents define exactly how the plant will operate.

Clash-free 3D models and stress-analyzed critical lines

Piping Design and 3D Plant Modeling

We build fully coordinated 3D plant models and produce all piping isometrics, line lists, piping material classes, and support designs. We run pipe stress analysis on all critical lines.

Equipment packages ready for procurement

Mechanical and Equipment Engineering

We produce equipment specifications, datasheets, and general arrangement drawings for all static and rotating equipment. We also manage vendor document review.

Construction-ready structural packages

Civil and Structural Engineering

Our civil team delivers foundation designs, structural steel detailing, and full calculation packages for all project structures and buildings.

Complete electrical packages for safe installation

Electrical Engineering

We produce single-line diagrams, cable routing layouts, electrical load schedules, and hazardous area classification drawings for the entire facility.

Full I&C packages aligned to DCS and SIS requirements

Instrumentation and Control Engineering

We deliver instrument indexes, datasheets, loop diagrams, junction box layouts, and control system architecture for process control and safety systems.

Accurate MTOs that prevent procurement delays

Material Take-Off and Procurement Support

We produce accurate bulk material take-offs (MTOs) for piping, steel, cable, and equipment, formatted for direct use by procurement teams.

No gaps between engineering and supplier deliverables

Vendor Document Management

We review and track all supplier and vendor drawings and data sheets, making sure every vendor document is approved and incorporated into the engineering package before construction.

WHY MONARCH INNOVATION

Why Choose Monarch Innovation For Detailed Engineering Services?

Monarch Innovation is not a drafting bureau. We are a full engineering partner. Our teams work across all disciplines in shared environments, producing coordinated packages that are right on the first issue.

ISO

ISO 9001 Certified Quality System

Our engineering processes are ISO 9001 certified. Every deliverable is traceable, auditable, and meets your project quality requirements.

IDC

Inter-Discipline Check on Every Deliverable

Every drawing and document passes an inter-discipline check (IDC) before it leaves our office. We catch cross-discipline conflicts before they become construction problems.

IP Protection from Day One

All project information is covered by NDA. Your engineering data, drawings, and models are secure throughout the project and transferred fully to you on completion.

Intelligent 3D Plant Modeling

We model your entire plant in 3D using AVEVA E3D, SP3D, or AutoCAD Plant 3D. You can see your plant before it is built and identify issues before construction begins.

ISO

ISO 9001 Certified Quality System

Our engineering processes are ISO 9001 certified. Every deliverable is traceable, auditable, and meets your project quality requirements.

IDC

Inter-Discipline Check on Every Deliverable

Every drawing and document passes an inter-discipline check (IDC) before it leaves our office. We catch cross-discipline conflicts before they become construction problems.

IP Protection from Day One

All project information is covered by NDA. Your engineering data, drawings, and models are secure throughout the project and transferred fully to you on completion.

Intelligent 3D Plant Modeling

We model your entire plant in 3D using AVEVA E3D, SP3D, or AutoCAD Plant 3D. You can see your plant before it is built and identify issues before construction begins.

FULL

Quote and Scope Within 24 Hours

Send us your project brief and we will return a detailed scope, deliverable schedule, and cost estimate within one business day.

E2E

Full Project Lifecycle Support

From FEED review through IFC issue, construction support, and as-built documentation, we support your project at every phase.

TRUE

True Multi-Discipline Integration

Our piping, civil, electrical, and instrumentation engineers work in a shared model environment, not in isolation. This is how we avoid the coordination gaps that cause rework.

FULL

Quote and Scope Within 24 Hours

Send us your project brief and we will return a detailed scope, deliverable schedule, and cost estimate within one business day.

E2E

Full Project Lifecycle Support

From FEED review through IFC issue, construction support, and as-built documentation, we support your project at every phase.

TRUE

True Multi-Discipline Integration

Our piping, civil, electrical, and instrumentation engineers work in a shared model environment, not in isolation. This is how we avoid the coordination gaps that cause rework.

Need Expert Detailed Engineering and Design Services?

Get a Free Consultation

TECHNOLOGIES WE USE

Detailed Engineering And Design Tools Used By Monarch Innovation

We use the same industry-standard tools that your in-house team and EPC contractor use. This means we can work directly inside your project environment without extra setup or conversion work.

3D Plant Design and Modeling

AVEVA E3D Design (formerly PDMS)
Intergraph SmartPlant 3D (SP3D)
AutoCAD Plant 3D
Autodesk Navisworks for clash detection
Bentley OpenPlant

Process and Simulation

Aspen HYSYS and Aspen Plus for process simulation
Caesar II for pipe stress analysis
HTRI Xchanger Suite for heat exchanger design
AFT Fathom and AFT Arrow for fluid flow analysis

Civil, Structural, and Electrical

STAAD.Pro and SAP2000 for structural analysis
ETAP for electrical power system design
AutoCAD Electrical
Tekla Structures for steel detailing
Revit Structure and Revit MEP

Instrumentation and Control

SmartPlant Instrumentation (INTOOLS / SPI)
EPLAN Electric P8
Elecdes Design Suite (EDS)

Document Management

AVEVA Engineering (Smart Plant Foundation)
Bluebeam Revu for review and markup
Intergraph Smart Plant Enterprise
Primavera P6 for schedule integration

OUR PROCESS

How Does The Detailed Engineering And Design Process Work?

Here is exactly how we deliver a detailed engineering project from start to finish.

Project Kick-Off and FEED Review

We receive your FEED package, design basis, and project requirements. We assign discipline leads and set up the master deliverable register and schedule.

Design Basis and Standards Confirmation

We confirm all applicable codes, client standards, and design criteria before engineering work begins. No surprises from undocumented requirements later in the project.

Multi-Discipline Engineering Execution

All discipline teams work in parallel in a shared project environment. We track progress weekly and report against the agreed schedule at every milestone.

Inter-Discipline Check and 3D Model Review

At defined milestones, we run formal IDC reviews and 3D model clash detection. All conflicts are resolved before documents are issued for client review.

Issued for Review (IFR) and Client Approval

We issue all deliverables for your review and incorporate your comments. Document revision cycles are controlled through formal transmittal management.

Issued for Construction (IFC) and Support

Final IFC packages are issued with full MTO and document index. We provide ongoing RFI response, change management, and as-built update services during construction.

Project Kick-Off and FEED Review

We receive your FEED package, design basis, and project requirements. We assign discipline leads and set up the master deliverable register and schedule.

Design Basis and Standards Confirmation

We confirm all applicable codes, client standards, and design criteria before engineering work begins. No surprises from undocumented requirements later in the project.

Multi-Discipline Engineering Execution

All discipline teams work in parallel in a shared project environment. We track progress weekly and report against the agreed schedule at every milestone.

Inter-Discipline Check and 3D Model Review

At defined milestones, we run formal IDC reviews and 3D model clash detection. All conflicts are resolved before documents are issued for client review.

Issued for Review (IFR) and Client Approval

We issue all deliverables for your review and incorporate your comments. Document revision cycles are controlled through formal transmittal management.

Issued for Construction (IFC) and Support

Final IFC packages are issued with full MTO and document index. We provide ongoing RFI response, change management, and as-built update services during construction.

BUSINESS BENEFITS

Benefits Of Detailed Engineering And Design Services For Your Project

Investing in high-quality detailed engineering saves time, money, and stress during construction. Here is what you can expect when you work with Monarch Innovation.

Less Field Rework

Clash-free 3D models and fully coordinated drawings mean construction teams can build from your packages without discovering conflicts on site.

Faster Construction Start

Complete and accurate IFC packages allow procurement and construction to start on schedule, without waiting for missing documents or unresolved engineering questions.

Lower Project Cost

Getting engineering right on the first issue avoids costly rework cycles, late procurement changes, and schedule overruns that drive up project costs.

Accurate Procurement

Precise material take-offs mean your procurement team orders the right materials in the right quantities. No shortfalls or expensive last-minute orders.

Regulatory Compliance

All deliverables are produced to the applicable international codes and documented for regulatory submissions, audits, and owner handover packages.

Construction Confidence

Your construction team starts work with complete, reviewed, and approved drawings. No gaps, no conflicts, no guesswork on site.

OUR ENGINEERING EDGE

Which Industries Need Detailed Engineering And Design Services?

Detailed engineering is needed in any industry that builds or upgrades physical plants, facilities, or infrastructure. Monarch Innovation has delivered projects across all the following sectors.

Oil and Gas

Upstream, midstream, and downstream facilities — refineries, gas processing plants, pipelines, and offshore topsides.

Chemical and Petrochemical

Multi-discipline DED for batch and continuous chemical plants, specialty chemical facilities, and solvent recovery units.

Power Generation

Thermal, combined-cycle, and renewable power plant engineering — from BOP systems to full electrical and I&C packages.

Water and Wastewater

Treatment plants, desalination systems, pump stations, and distribution infrastructure requiring full multi-discipline packages.

Mining and Minerals

Process plant engineering for mining, mineral processing, and metallurgical facilities from feasibility through IFC.

Pharmaceutical and Life Sciences

GMP-compliant engineering packages for API manufacturing, formulation plants, and cleanroom facilities.

Industrial and Manufacturing

Manufacturing plants, industrial buildings, utility facilities, and process support structures with full civil, structural, MEP, and fire protection engineering.

Infrastructure and Defence

Critical infrastructure and defence facility engineering with full traceability documentation, classified protocols, and applicable regulatory compliance.

Don't see your industry? We work across all heavy process and industrial sectors.

Talk to Our Engineering Team →
